Belden 8434 25 AWG 1 Pair 25 AWG 2 Conductor 7x33 Stranding 400V Electronic Cable

Description:

Electronic, 1 Pair+2 Conductors 25 AWG (7x33) Tinned Copper+Tinned Copper Covered Steel, PE Insulation, Individual and Overall Beldfoil Shield, PVC Outer Jacket.

Insulation:

• Material: PE - Polyethylene
• Nom. Thickness: 0.013 in (0.33 mm)
• Nom. Insulation Diameter: 0.047 in (1.2 mm)

Inner Shield:

Element: Pair(s):-
• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage: 100%
• Drainwire Type: 25 AWG (7x33) TC+TCCS

Outer Shield:

• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage: 100%

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.02 in (0.51 mm)
• Nom. Diameter: 0.165 in

Standards:

• Voltage Rating: 400 V.
• Operating Temperature: -20°C to +80°C

Applications:

• low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, …); line level audio; computer communication; panel wiring
