2591910000 - 3.50mm Female PCB Connector with 12 Poles, 180° Angle (Pack of 36)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a reliable PCB plug-in connector, perfect for field applications This female connector has a 350 mm pitch and accommodates 12 poles at a 180° angle Utilizing a clamping yoke method, it securely connects wires with cross-sections from 02 to 15 mm² The connector adheres to stringent safety standards, proudly showcasing RoHS and REACH certifications With a rated voltage of 320 V and a maximum current capacity of 17 A, this connector is both safe and efficient.

It’s conveniently packaged in a box for easy storage and transport.

Features and Benefits:

•Clamping range allows for versatile wire sizes from 0.2 to 1.5 mm².

•Assembly features touch-safe protection according to standards.

•Can accommodate various wire types including fine-wired conductors.

•Durable construction with a minimum volume resistance of ≤5 mΩ.

•Ideal for PCB plug-in connections in electronic devices.

Specifications:
