2578000000 - 3.50mm Pitch 8-Pole Female PCB Connector 180° Orientation (Pack of 84)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a versatile PCB connector designed specifically for female plug applications This connector boasts a pitch of 350 mm and accommodates 8 poles with a convenient 180° orientation Its innovative PUSH IN mechanism, complemented by an easy-to-use push button, simplifies the connection process Capable of handling a maximum clamping range of 15 mm², this component is ideal for various electrical applications.

In terms of electrical specifications, it supports an IEC rating of 320 V at 134 A for cross-sectional areas between 014 mm² and 15 mm², and a UL rating of 300 V at 95 A for wire sizes ranging from AWG 30 to AWG 16 For convenient distribution, each connector is packaged in a box, ensuring it remains safe during transport.

Features and Benefits:

•PUSH IN connection method with push button.

•Can be coded for secure connections.

•Touch-safe protection according to DIN VDE 57 106.

•Housing material is PA 66 GF 30 which is flame retardant (UL 94 V-0).

•RoHS compliant without exemptions.

Specifications:
