2563350000 - 3-Pole Female PCB Connector, 3.81mm Pitch, 180° Connection (Pack of 50)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a reliable PCB female connector designed for seamless integration This connector features a compact 381 mm pitch and includes 3 poles for efficient connectivity It utilizes a PUSH IN actuator for a straightforward 180° connection, making installation a breeze Capable of accommodating a maximum clamping range of 15 mm², this product ensures robust electrical connections It operates safely at IEC voltage levels of 320 V and supports currents up to 17.

5 A, with a UL voltage rating of 300 V and a maximum current of 10 A Each connector is conveniently packaged in a box for easy storage and transport.

Features and Benefits:

•Compliant with RoHS without exemption.

•Touch-safe protection per DIN VDE 57 106 and 0470.

•Can be coded for secure connections.

•Insulating material is PA 66 GF 30.

•Suitable for fine-wired and flexible conductors.

Specifications:
