2563330000 - 3-Pole 3.81mm PCB Connector with 90-Degree Flange Design (Pack of 78)

2563330000 - 3-Pole 3.81mm PCB Connector with 90-Degree Flange Design (Pack of 78)

SKU: SKU: 2563330000   Download PDF

Select a Variant:
  • 2563330000 - 3-Pole 3.81mm PCB Connector with 90-Degree Flange Design (Pack of 78)
Qty:
Regular price Now $150.50   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $150.50 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing a robust male header PCB plug-in connector featuring a convenient flange design This connector utilizes a through-hole technology (THT) for reliable solder connections and has a pitch of 381 mm It includes three pins arranged in a 90-degree configuration, with tinned solder pins measuring 32 mm in length and finished in black Each unit is securely packaged in a box and complies with various regulatory standards, ensuring quality and performance.

Features and Benefits:

    •Touch-safe protection according to DIN VDE 57 106.

    •Can be coded.

    •Plugging force per pole is a maximum of 7 N.

    •Pulling force per pole is a maximum of 5 N.

    •Compliant with RoHS standards.

Specifications:

 Number of poles 3
 Solder pin length 3.2 mm
 Voltage rating (IEC) 320 V
 Current rating (IEC) 17.5 A
 Pitch 3.81 mm
 Insulating material PA GF
 Operating temperature, max. 120 °C
 Storage temperature, min. -40 °C
 Volume resistance ≤5 mΩ
 UL voltage rating 300 V
 Contact material Cu-alloy
