2555300000 - 5.08mm Female PCB Connector, 7 Poles, 270° Clamping (Pack of 36)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the BLZP 508HC/07/270F SN BK BX SO female PCB plug-in connector, engineered for optimal performance with a 508 mm pitch This connector supports up to 7 poles and features a 270° clamping yoke connection It can handle conductor cross-sections from 02 to 4 mm², meeting IEC compliance for voltages up to 400 V and currents up to 23 A For additional safety, it holds UL ratings for a maximum of 300 V and a current of 20 A, compatible with wire gauges between AWG 26 and AWG 12.

Although this item is discontinued, it will remain available for purchase until August 31, 2025, and comes securely packaged in a box.

Features and Benefits:

•Complies with RoHS and REACH regulations.

•Touch-safe protection according to DIN VDE standards.

•Can be coded for secure connections.

•Easy installation with clamping yoke connection.

Specifications:
