2541640000 - 3.81mm Female PCB Connector, 13 Poles, 180° Orientation (Pack of 50)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the BCF 381/13/180 AU BK BX, a premium female plug PCB connector that offers exceptional performance with its 381 mm pitch and 13-pole configuration This connector is engineered with a clamping range accommodating wires up to 15 mm², ensuring reliable and secure connections With a 180° orientation, it incorporates an efficient PUSH IN mechanism equipped with an actuator for easy installation.

Designed to meet IEC standards, it supports voltages up to 320 V and currents up to 175 A Each unit is conveniently packaged in a box, making it perfect for your electronic projects.

Features and Benefits:

•Compliant with RoHS regulations.

•No SVHC above 0.1 wt% in accordance with REACH.

•Safe from finger touch as per DIN standards.

•Can be coded for various applications.

•Insulating material: PA 66 GF 30.

•Highly durable with a UL 94 flammability rating of V-0.

•Gold-plated contact surface.

•Long storage temperature range from -40 °C to 70 °C.

Specifications:
