2535450000 - 14-Pole Male PCB Connector, 3.5mm Pitch, 180° Angle (Pack of 30)

2535450000 - 14-Pole Male PCB Connector, 3.5mm Pitch, 180° Angle (Pack of 30)

SKU: SKU: 2535450000   Download PDF

Select a Variant:
  • 2535450000 - 14-Pole Male PCB Connector, 3.5mm Pitch, 180° Angle (Pack of 30)
Qty:
Regular price Now $130.40   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $130.40 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing our male header PCB plug-in connector, perfect for THT/THR soldering applications This robust connector supports a voltage of up to 320 V and a current rating of 15 A With a 35 mm pitch and a configuration of 14 poles arranged at a 180° angle, it provides excellent connectivity The solder pin length measures 32 mm, ensuring secure connections Each unit is conveniently packaged in a sleek black box, making it easy to store and transport.

Ideal for various electronic projects and setups.

Features and Benefits:

    •Designed for board connection.

    •THT/THR solder connection.

    •Touch-safe protection in accordance with DIN VDE 57 106.

    •Can be coded for identification.

    •Compliant with RoHS regulations.

    •Long temperature range for storage and operation.

Specifications:

 Number of poles 14
 Solder pin length 3.2 mm
 Rated voltage 320 V
 Rated current 15 A
 Storage temperature -40 to 70 °C
 Operating temperature -50 to 100 °C
 Insulating material LCP GF
 Contact material Cu-alloy
 IP protection IP20 plugged / IP10 unplugged
 Packaging Box
 Dimensions Width: 56 mm
