2439990000 - 10-Pole 2.50mm PCB Connector with THT Solder, 180° Angle (Pack of 100)

2439990000 - 10-Pole 2.50mm PCB Connector with THT Solder, 180° Angle (Pack of 100)

SKU: SKU: 2439990000   Download PDF

Select a Variant:
  • 2439990000 - 10-Pole 2.50mm PCB Connector with THT Solder, 180° Angle (Pack of 100)
Qty:
Regular price Now $226.60   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $226.60 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Discover the functionality of this PCB plug-in connector, featuring a male header designed for through-hole (THT) soldering This connector boasts a compact 250 mm pitch and is equipped with 10 poles arranged at a 180° angle in a box configuration As part of the OMNIMATE Signal series, it adheres to RoHS compliance standards, ensuring it meets environmental safety regulations Perfect for various electronic applications, this connector delivers reliability and performance.

Features and Benefits:

    •THT solder connection.

    •180° outgoing elbow.

    •Compliant with RoHS without exemption.

    •Insulating material: PA 66.

    •Touch-safe protection according to DIN VDE standards.

    •This connector can be used in board connections and is suitable for various electronic assembly applications..

Specifications:

 Rated voltage (IEC) 320 V
 Rated current (min. number of poles, Tu=20°C) 6 A
 Rated current (min. number of poles, Tu=40°C) 6 A
 Operating temperature, min. -40 °C
 Operating temperature, max. 105 °C
 Storage temperature, min. -40 °C
 Storage temperature, max. 70 °C
 Number of poles 10
 Solder pin length (l) 3.2 mm
 Pitch in mm (P) 2.5 mm
 Plugging cycles 25
 Net weight 1.764 g
 Manufacturer AIM ELECTRONICS
 UL File Number E60693
 Contact material Copper alloy
 Contact surface tinned
 Flammability rating V-0
