2426530000 - 18-Pole 5.08mm Female PCB Connector at 225° Angle (Pack of 18)

2426530000 - 18-Pole 5.08mm Female PCB Connector at 225° Angle (Pack of 18)

SKU: SKU: 2426530000   Download PDF

Select a Variant:
  • 2426530000 - 18-Pole 5.08mm Female PCB Connector at 225° Angle (Pack of 18)
Qty:
Regular price Now $399.52   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $399.52 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing a versatile female plug PCB connector featuring a compact 508 mm pitch This connector is designed with 18 poles positioned at a 225° angle and utilizes a secure clamping yoke connection method, accommodating a maximum clamping capacity of 4 mm² Certified for RoHS compliance and holding a UL file number E60693, this product is suitable for various voltage applications It comes neatly packaged in a box and is noted as discontinued, making it a unique addition for specific connectivity needs.

Features and Benefits:

    •Field connection type.

    •Touch-safe protection according to DIN VDE standards.

    •Compliant with RoHS without exemptions.

    •Gold-plated contact surface.

    •Clamping yoke connection method.

Specifications:

 Rated Voltage (IEC) 400 V / 0.2 - 4 mm²
 Rated Voltage (UL) 300 V / 15 A / AWG 26 - AWG 12
 Pitch 5.08 mm
 Number of poles 18
 Depth 23.6 mm
 Height 15.7 mm
 Width 101.39 mm
 Plugging cycles 25
 Protection Degree IP20
 Operating Temperature (min) -50 °C
 Operating Temperature (max) 100 °C
 Storage Temperature (min) -40 °C
 Storage Temperature (max) 70 °C
