1945020000 - 21-Pole 5.08mm PCB Female Connector with 180° Angle (Pack of 12)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a reliable PCB plug-in female connector with a 508 mm pitch This connector offers 21 poles arranged in a 180° configuration and features a clamping yoke for secure connections, accommodating a clamping range of up to 4 mm² Each connector is conveniently packaged in a box for easy storage or transport Built to meet IEC standards, it supports voltages up to 400 V with a current rating of 23 A, and complies with UL standards up to 300 V at a current rating of 20 A.

Additionally, it is RoHS compliant, ensuring it meets environmental safety regulations.

Features and Benefits:

•Complies with RoHS standards without any exemptions.

•Allows for flexibility with different conductor sizes ranging from 0.2 mm² to 4 mm².

•Touch-safe protection ensures safety during use.

•Can be coded for organized connections.

•Available in orange color.

Specifications:
