1924500000 - Blue Double-Tier Terminal 50.5mm, 800V, 24A Rated (Pack of 50)

Description:

Introducing the ZDK 25/3AN BL, a dual-tier blue terminal featuring a reliable tension-clamp connection that supports up to 800 V and 24 A This terminal is capable of accommodating wire cross-sections as large as 25 mm² It comes with UL certification (file number E60693) for added assurance of quality Designed for quick and efficient installation, its dimensions are optimized with a depth of 505 mm, height of 93 mm, and a width of 5.

1 mm, while weighing in at just 1512 g Fully compliant with RoHS standards, this terminal contains no restricted substances and keeps SVHC levels below 01 wt% Add this reliable component to your electrical applications for enhanced performance and safety.

Features and Benefits:

•Features a tension-clamp connection for reliable electrical contact.

•Suitable for plug-in cross-connectors with an option for end cover plate installation.

•Explosion-tested version enhances safety in hazardous environments.

•Compliant with IEC 60947-7-1 standards.

Specifications:
