1682800000 - 5.08mm PCB Connector, 9 Poles, 180° Angle, THT Soldering (Pack of 36)

1682800000 - 5.08mm PCB Connector, 9 Poles, 180° Angle, THT Soldering (Pack of 36)

SKU: SKU: 1682800000   Download PDF

Select a Variant:
  • 1682800000 - 5.08mm PCB Connector, 9 Poles, 180° Angle, THT Soldering (Pack of 36)
Qty:
Regular price Now $155.94   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $155.94 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Enhance your connectivity with this efficient PCB plug-in connector, crafted specifically for female headers It features secure dovetail fixings and utilizes a THT solder connection for reliable performance With a pitch of 508 mm and accommodating 9 poles, this connector operates at a 180° angle The solder pins, measuring 32 mm in length, come tinned for optimum functionality Housed in an orange box, this connector is both practical and visually distinctive.

Features and Benefits:

    •Compliant with RoHS without any exemptions.

    •Touch-safe protection according to DIN VDE 57 106 and IP20 standard.

    •Can be coded for specific applications.

    •Has a maximum pulling and plugging force of 5 N per pole.

    •Volume resistance is less than or equal to 5 mΩ.

Specifications:

 Number of poles 9
 Pitch in mm (P) 5.08 mm
 Number of solder pins per pole 2
 Solder pin length (l) 3.2 mm
 Rated voltage for surge voltage class / pollution degree II/2 400 V
 Rated current, max. number of poles (Tu=20°C) 16 A
 Insulation resistance 10^8 Ω
 Operating temperature, min. -50 °C
 Operating temperature, max. 100 °C
 Storage temperature, min. -40 °C
 Storage temperature, max. 70 °C
 Contact material Copper alloy
 Color chart (similar) RAL 2000
 UL 94 flammability rating V-0
 Environmental Product Compliance Compliant without exemption
