1510090000 - 3-Pole 3.5mm Male PCB Connector with 180° Elbow (Pack of 100)

1510090000 - 3-Pole 3.5mm Male PCB Connector with 180° Elbow (Pack of 100)

SKU: SKU: 1510090000   Download PDF

Select a Variant:
  • 1510090000 - 3-Pole 3.5mm Male PCB Connector with 180° Elbow (Pack of 100)
Qty:
Regular price Now $103.10   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $103.10 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing the SL 350/03/180G 32SN RD BX CO connector, a specialized male header plug-in designed exclusively for PCB applications This connector showcases a unique closed side design and incorporates a THT solder connection with a pitch measurement of 35 mm It features three pins arranged in a 180° elbow orientation for optimal circuit alignment Each solder pin measures 32 mm in length and comes with a tin coating for enhanced conductivity.

Packaged securely in a box, this connector meets RoHS standards, making it a responsible choice for environmentally-conscious users.

Features and Benefits:

    •Type of connection allows for easy integration on the PCB.

    •Touch-safe protections ensure safety during use.

    •Can be coded to prevent incorrect connections.

    •Designed to be finger-safe when plugged in.

Specifications:

 Number of poles 3
 Rated voltage 320 V / 300 V
 Rated current 17 A / 10 A
 Storage temperature -40°C to 70°C
 Operating temperature -50°C to 100°C
 Solder pin length 3.2 mm
 Volume resistance ≤5 mΩ
 Insulating material PBT
 Touch-safe protection finger-safe plugged/ back-of-hand-safe unplugged
 Pin series quantity 1
 Solder pin dimensions d = 1.2 mm
 Short-time withstand current resistance 3 x 1s with 100 A
