Product Information
Belden 8538 24 AWG 1 Conductor Solid Tinned Copper 1000V Lead Wire
Description:
Low Temp Plastic Lead Wire, 24 AWG (Solid) Tinned Copper, PVC Insulation, TYPE MW MIL-W-76C-PVC 1000V 80C.
Insulation:
• Material: PVC - Polyvinyl Chloride
• Nominal Diameter: 0.055 in
• Nominal Wall Thickness: 0.017 in
Standards:
• Voltage Rating: 1000 V RMS
• Military Compliance: MIL-W-76C Type MWP
Applications:
• inter-connection circuits, internal wiring of computer and electronic equipment, (Type MW) MIL-W-76C-Low Temp applications
Specifications:
• Size (AWG): 24
• No. of Conductor: 1
• Stranding: Solid
• Conductor Material: TC - Tinned Copper
• Part Number: 8538
• Size (AWG): 24
• No. of Conductor: 1
• Stranding: Solid
• Conductor Material: TC - Tinned Copper
• Part Number: 8538
