2698390000 - 5.08mm Male PCB Connector, 4 Poles, Basalt Grey (Pack of 100)

2698390000 - 5.08mm Male PCB Connector, 4 Poles, Basalt Grey (Pack of 100)

SKU: SKU: 2698390000   Download PDF

Select a Variant:
  • 2698390000 - 5.08mm Male PCB Connector, 4 Poles, Basalt Grey (Pack of 100)
Qty:
Regular price Now $106.91   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $106.91 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Enhance your connectivity with this PCB plug-in connector equipped with a male header featuring an open side design and through-hole (THT) solder connection With a pin pitch of 508 mm and four poles, this connector is perfect for various applications The solder pins measure 32 mm in length and have a tinned finish for added durability Presented in a sophisticated basalt grey color, this connector adheres to RoHS standards, making it a reliable and environmentally friendly choice.

Each unit is conveniently packaged in a box for easy storage and handling.

Features and Benefits:

    •Touch-safe protection: fing-safe when unplugged and back-of-hand safe when plugged in.

    •Can be coded for assembly flexibility.

    •High durability with up to 25 plugging cycles.

    •Rated for use in a wide temperature range from -50°C to 100°C.

    •RoHS compliant without exemption.

    •Made with insulating material PA GF.

Specifications:

 IEC Voltage Rating 400 V
 UL Voltage Rating 300 V
 Rated Current 24 A
 Rated Voltage (Use group B / CSA) 300 V
 Pitch 5.08 mm
 Protection Degree IP20
 Storage Temperature -40°C to 70°C
 Operating Temperature -50°C to 100°C
 Material Data {'Insulating Material': 'PA GF', 'Contact Material': 'Cu-alloy', 'UL 94 Flammability Rating': 'V-0'}
