1740651001 - 5-Pole 3.5mm PCB Connector with Clamping Yoke (Pack of 102)

1740651001 - 5-Pole 3.5mm PCB Connector with Clamping Yoke (Pack of 102)

SKU: SKU: 1740651001   Download PDF

Select a Variant:
  • 1740651001 - 5-Pole 3.5mm PCB Connector with Clamping Yoke (Pack of 102)
Qty:
Regular price Now $394.77   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $394.77 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing this versatile PCB plug-in connector, crafted with a female plug design and a 350 mm pitch This connector boasts 5 poles, enhanced by a secure clamping yoke connection It accommodates a maximum wire cross-section of 15 mm², making it ideal for various applications Packaged conveniently in a box, it complies with RoHS standards, ensuring it meets environmental and safety regulations Perfect for your electronic connection needs!.

Features and Benefits:

    •Suitable for field connection.

    •Touch-safe protection acc. to DIN VDE 57 106.

    •Can be coded for user-specific applications.

    •Safe from finger touch.

    •IP20 protection degree when fully mounted.

Specifications:

 Rated Voltage (IEC) 320 V / 17 A / 0.2 - 1.5 mm²
 Rated Voltage (UL) 300 V / 10 A / AWG 28 - AWG 14
 Width 17.5 mm
 Height 13 mm
 Depth 18.5 mm
 Protection Degree IP20
 Number of Poles 5
 Conductor Outlet Direction 180°
 Stripping Length 6 mm
 Plugging Cycles 25
 Net Weight 4.446 g
 Material PBT
 Flammability Rating V-0
 Operating Temperature Range -50 °C to +100 °C
 Storage Temperature Range -40 °C to +70 °C
