1568241687 - Yellow CableLine Markers, 1.3-3mm Diameter, RoHS Compliant (Pack of 500)

1568241687 - Yellow CableLine Markers, 1.3-3mm Diameter, RoHS Compliant (Pack of 500)

SKU: SKU: 1568241687 Download PDF

Variant:
  • 1568241687 - Yellow CableLine Markers, 1.3-3mm Diameter, RoHS Compliant (Pack of 500)
Regular price Now $29.82
Regular price BEFORE   $0.00 Sale price Now $29.82
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CableLine, a set of conductor and cable markers specifically crafted for cables with diameters ranging from 13 mm to 3 mm, featuring a width of 34 mm This vibrant yellow item adheres to RoHS regulations, ensuring it is free from substances of very high concern (SVHC) above 01 wt% Each marker is neatly packaged on a reel, providing one marker for each combination Made from soft PVC without cadmium, this product prioritizes both safety and environmental responsibility.

Suitable for a variety of industries, including processing machinery, these markers function optimally within a temperature range of -30 °C to 80 °C Enhanced with striking upper-case letter printing and employing a reliable hot-embossing printing technique, the CableLine ensures clear and durable identification for your wiring needs.

Features and Benefits:

    •Compliant with RoHS without exemption.

    •Soft PVC construction without cadmium.

    •Halogen-free.

    •Suitable for various industries including processing and machinery.

    •Standardized hot-embossing printing method.

    •Conductor and cable marking.

Specifications:

 Operating temperature range -30...80 °C
 Depth 3.5 mm
 Height 3 mm
 Width 3.4 mm
 Conductor cross-section, max 1.5 mm²
 Conductor cross-section, min 0.2 mm²
 Conductor O.D. 1.3 - 3 mm
 Imprint X
 Printing method hot-embossing
 UL 94 flammability rating V-0
 Number of markers per combination 1 Reel
 Number of markers per packaging unit
 Orientation of print horizontal
 Printed characters Upper-case letters
 Material colour according to resistance code 4
 ETIM 6.0 EC001530
 ETIM 7.0 EC001530
 ETIM 8.0 EC001530
 ETIM 9.0 EC001530
 ETIM 10.0 EC001530
 ECLASS 9.0 27-40-04-01
 ECLASS 9.1 27-40-04-01
 ECLASS 10.0 27-40-04-01
 ECLASS 11.0 27-28-11-02
 ECLASS 12.0 27-28-11-02
 ECLASS 13.0 27-28-11-02
 ECLASS 14.0 27-28-11-02
 ECLASS 15.0 27-28-11-02
