1488480000 - Compact LED Light for Extreme Temperatures -40 °C to 70 °C
1488480000 - Compact LED Light for Extreme Temperatures -40 °C to 70 °C
SKU: SKU: 1488480000 Download PDF
- 1488480000 - Compact LED Light for Extreme Temperatures -40 °C to 70 °C
- 1488480000 - Compact LED Light for Extreme Temperatures -40 °C to 70 °C
Couldn't load pickup availability
Description:
Meet the FP DUO LED DC HQ8, a versatile and compact LED lighting solution suitable for a wide range of uses This durable light operates efficiently in extreme temperatures, ranging from -40 °C to 70 °C, and can be stored safely between -40 °C and 85 °C Additionally, it adheres to RoHS standards, with UL certification number E345151 for your peace of mind .
Features and Benefits:
•LED operating life exceeds 50,000 hours.
•Protection class II and degree of IP54.
•Short-circuit protection is integrated.
•Arbitrary mounting position for installation.
•Vibration resistance classified as 3M3 sinusoidal, stationary.
•Halogen-free construction.
Specifications:
| Height | 128 mm |
| Width | 104 mm |
| Length | 271 mm |
| Net weight | 662 g |
| Operating temperature | -40 °C to 70 °C |
| Storage temperature | -40 °C to 85 °C |
| LED Light Colour | Cool White, 6000K |
| Input Voltage | 21.6 V ... 144 V DC |
| Power Rating | 5 W |
| DC Input Voltage Range | 24...120 V DC |
| Humidity | 92 % @ 25 °C |
| Amplitude of Acceleration | 5 m/s² (@ 9-200 Hz) |
| Insulation Voltage | <500 V (housing/PE) |
| Shock Resistance | Class 3M3 portable |
| Surge Voltage Category | II |
| Connector Cross-Section Max | 2.5 mm² |
| Connector Cross-Section Min | 0.5 mm² |
| Pollution Severity | 2 |
| Peak Acceleration, Type L | 70 m/s² |
| Efficiency Class | E |
| Amplitudes of Deflection | 1.5 mm (2-9 Hz) |
| Type of Connection | Plug-in connector with fixed number of poles, HQ 8 |
| UL 94 Flammability Rating | V-0 |
