Description:

Introducing the TRANSCLINIC 14I+, a product designed for photovoltaic applications and compliant with RoHS standards This item comes with comprehensive ordering details, including its order number, type, GTIN, and available quantity Measuring 3689 mm in length, 1095 mm in width, and 922 mm in height, it has a net weight of 1,310 grams It operates efficiently in temperatures ranging from -20°C to 70°C and is suitable for use at altitudes up to 3000 meters.

Features and Benefits:

•MODBUS RS485 RTU communication.

•Shunt resistance of 1 mOhm for current measuring.

•Digital inputs operate at 0.5 V low and 15 ... 24 V high.

•Can handle a maximum current of 20 A DC at temperatures between -25°C to +70°C.

•Supports up to 14 strings.

•Measurement range from 3 to 20 A DC.

•Power consumption is less than 1500 mW.

•Rated for 1000 V DC.
