0252711605 - Yellow PVC Cable Markers 5mm x 4.2mm for Conductor Identification (Pack of 100)

0252711605 - Yellow PVC Cable Markers 5mm x 4.2mm for Conductor Identification (Pack of 100)

SKU: SKU: 0252711605 Download PDF

Variant:
  • 0252711605 - Yellow PVC Cable Markers 5mm x 4.2mm for Conductor Identification (Pack of 100)
Regular price Now $6.61
Regular price BEFORE   $0.00 Sale price Now $6.61
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CLI C 1-6 GE/SW 84 MP, the ideal solution for marking conductors and cables Crafted from soft PVC free of cadmium, this marking device comes in an eye-catching yellow hue It boasts compact dimensions of 5mm in depth, 6mm in height, and 42mm in width, making it perfect for various applications This product operates effectively in a temperature range from -30 to 80 °C and adheres to RoHS standards, ensuring it contains no SVHC over 0.

1 wt% The hot-embossing printing method allows for flexibility in print orientation, accommodating both vertical and horizontal layouts.

Features and Benefits:

    •Available in soft PVC without cadmium.

    •Compliant with RoHS standards.

    •Printing method is hot-embossing.

    •Helps in easy identification of cables.

    •Used for marking conductors and cables in various applications including process and machinery.

Specifications:

 Depth 5 mm
 Height 6 mm
 Width 4.2 mm
 Operating temperature range -30...80 °C
 Conductor O.D. (min) 2.5 mm
 Conductor O.D. (max) 5 mm
 Conductor cross-section (min) 1.5 mm²
 Conductor cross-section (max) 4 mm²
 UL 94 flammability rating V-0
 Number of markers per combination 1 Component part = Conductor and cable markers
 Orientation of print horizontal
 Imprint 84
 ETIM 6.0 EC001530
 ETIM 7.0 EC001530
 ETIM 8.0 EC001530
 ETIM 9.0 EC001530
 ETIM 10.0 EC001530
 ECLASS 9.0 27-40-04-01
 ECLASS 9.1 27-40-04-01
 ECLASS 10.0 27-40-04-01
 ECLASS 11.0 27-28-11-02
 ECLASS 12.0 27-28-11-02
 ECLASS 13.0 27-28-11-02
 ECLASS 14.0 27-28-11-02
 ECLASS 15.0 27-28-11-02
