Belden 9272 20 AWG 2 Conductor 7x28 Stranding 78 Ohm Twinax Cable
Belden 9272 20 AWG 2 Conductor 7x28 Stranding 78 Ohm Twinax Cable
SKU: SKU: NES9272 Download PDF
Select a gauge:
- Belden 9272 20 AWG 2 Conductor 7x28 Stranding 78 Ohm Twinax Cable
- Belden 9272 20 AWG 2 Conductor 7x28 Stranding 78 Ohm Twinax Cable
Length:
FT
Enter footage in the box - Cut to one length. Min 1 ft - Max 10000 ft.
Unit price
per
Sold out
Shipping calculated at checkout.
IN STOCK Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
Couldn't load pickup availability
Product Information
Belden 9272 20 AWG 2 Conductor 7x28 Stranding 78 Ohm Twinax Cable
Description:
78 Ohm Twinax, 20 AWG stranded (7x28) .038" tinned copper conductors, polyethylene insulation, tinned copper braid shield (93% Coverage), PVC jacket.
Insulation:
• Material: PE - Polyethylene
• Nominal Diameter: 0.0755 in
Outer Shield:
• Layer 1: Type Braid, Tinned Copper (TC) Material, Coverage [%] 93%
Outer Jacket:
• Material: PVC - Polyvinyl Chloride
• Nom. Diameter: 0.244 in
Specifications:
• Size (AWG): 20
• No. of Conductor: 2
• Stranding: 7x28
• Nom. Diameter: 0.038 in
• Impedance: 78 Ohm
• Conductor Material: TC - Tinned Copper
• Part Number: 9272
• Size (AWG): 20
• No. of Conductor: 2
• Stranding: 7x28
• Nom. Diameter: 0.038 in
• Impedance: 78 Ohm
• Conductor Material: TC - Tinned Copper
• Part Number: 9272
