Belden 89880 12 AWG 1 Conductor Solid Bare Copper 600V Coax Cable

Description:-

Ethernet 50 Ω 10BASE5, 12 AWG solid bare copper conductor, foam FEP insulation, Overall Duobond II+Tinned Copper Braid (90%)+Duofoil+Tinned Copper Braid (90%) Shield, fluorocopolymer jacket, CMP

Insulation:-

• Material: FEP - Fluorinated Ethylene Propylene (Foam)
• Nom. Insulation Diameter: 0.245 in (6.22 mm)

Outer Shield:-

• Layer: 1
• Shield Type: Tape
• Material: Tri-Laminate (Alum+Poly+Alum)
• Coverage: 100%
• Material Trade Name: Duobond II

• Layer: 2
• Shield Type: Braid
• Material: Tinned Copper (TC)
• Coverage: 90%

• Layer: 3
• Shield Type: Tape
• Material: Tri-Laminate (Alum+Poly+Alum)
• Coverage: 100%
• Outer Shield Trade Name: Duofoil

• Layer: 4
• Shield Type: Braid
• Material: Tinned Copper (TC)
• Coverage: 90%

Outer Jacket:-

• Material: PVDF - Polyvinylidene Fluoride
• Nom. Diameter: 0.365 in (9.27 mm)
• Overall Nominal Diameter: 0.365 in (9.27 mm)

Standards:-

• UL Voltage Rating: 600 V
• Nom. Characteristic Impedance: 50 Ohm
• Operating Temperature Range: -25°C to +150°C

Applications:-

• Thick Ethernet (IEEE 802.3 10BASE5)

Specifications:-

• Size (AWG): 12
• No. of Conductor: 1
• Stranding: Solid
• Nom. Diameter: 0.086 in
• Conductor Material: BC - Bare Copper
• Part Number: 89880
