Belden 88641 24 AWG 2 Conductor 7x32 Stranding Tinned Copper 300V Electronic Cable

Description:

High Temperature Electronic, 2 Conductor 24 AWG (7x32) Tinned Copper, FEP Insulation, Overall Beldfoil Shield, FEP Outer Jacket, CMP.

Insulation:

• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Thickness: 0.006 in (0.15 mm)
• Nom. Insulation Diameter: 0.036 in (0.91 mm)

Outer Shield:

• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage: 100%
• Drainwire Type: 24 AWG (7x32) TC - Tinned Copper

Outer Jacket:

• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Thickness: 0.015 in (0.38 mm)
• Nom. Diameter: 0.106 in (2.69 mm)
• Overall Cable Diameter (Nominal): 0.106 in (2.69 mm)

Standards:

• Voltage Rating: 300 V (CMP)
• Operating Temperature: -20°C to +150°C

Applications:

• extreme high/low temperature environments; chemical resistant; outdoor and burial applications; low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, …); line level audio; voice communications; panel wiring

Specifications:

• Size (AWG): 24
• No. of Conductor: 2
• Stranding: 7x32
• Conductor Material: TC - Tinned Copper
• Part Number: 88641
