Belden 8641 24 AWG 2 Conductor 7x32 Stranding Tinned Copper 300V Electronic Cable

Description:

Electronic, 2 Conductor 24 AWG (7x32) Tinned Copper, PE Insulation, Overall Beldfoil Shield, PVC Outer Jacket, CM.

Insulation:

• Material: PE - Polyethylene
• Nom. Thickness: 0.017 in (0.43 mm)
• Nom. Insulation Diameter: 0.056 in (1.4 mm)

Outer Shield:

• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage: 100%
• Drainwire Type: 24 AWG (7x32) TC

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.025 in (0.64 mm)
• Nom. Diameter: 0.168 in (4.27 mm)
• Overall Cable Diameter (Nominal): 0.168 in (4.27 mm)

Standards:

• Voltage Rating: 300 V (UL AWM 2092, CM)
• Operating Temperature Range: -20°C to +80°C

Applications:

• low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, …); line level audio; computer communication; panel wiring
