Belden 83955 20 AWG 1 Pair 7x28 Stranding Chromel and Constantan 300V Type EX Thermocouple Cable

Description:-

Type EX Thermocouple, 1 Pair 20 AWG (7x28) Chromel+Constantan, FEP Insulation Pur, Red Color Code, Purple FEP Outer Jacket, CL3P 200C PLTC SUN RES.

Insulation:-

• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Thickness: 0.01 in (0.25 mm)
• Nom. Insulation Diameter: 0.058 in (1.5 mm)

Outer Shield:-

• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage: 100%
• Drainwire Type: 22 AWG (7x30) TC - Tinned Copper

Outer Jacket:-

• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Thickness: 0.012 in (0.30 mm)
• Nom. Diameter: 0.145 in
• Overall Cable Diameter (Nominal): 0.145 in

Standards:-

• UL Voltage Rating: 300 V
• Operating Temperature Range: -70°C To +200°C

Applications:-

• Industrial Control, Raceways, Cable trays and ducts, Digital Control, Instruments (4-20ma, 0-10v, ...), low voltage digital control (24v, …), RTD, control circuits, distributed control system (DCS), programmable logic controller (PLC), Solenoids, Valves, actuators, positioners

Specifications:-

• Size (AWG): 20
• No. of Pairs: 1
• Stranding: 7x28
• Conductor Material: Chromel and Constantan
• Part Number: 83955
