Belden 83950 20 AWG 1 Pair 7x28 Stranding Iron and Constantan 300V Type JX Thermocouple Cable

Description:

Type JX Thermocouple, 1 Pair 20 AWG (7x28) Iron+Constantan, FEP Insulation Wht, Red Color Code, Black FEP Outer Jacket, CL3P 200C PLTC SUN RES.

Insulation:

• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Thickness: 0.01 in (0.25 mm)
• Nom. Insulation Diameter: 0.052 in (1.3 mm)

Outer Shield:

• Shield Type: Tape
• Material: Tri-Laminate (Alum+Poly+Alum)
• Coverage: 100%
• Drainwire Type: 22 AWG (7x30) TC - Tinned Copper

Outer Jacket:

• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Thickness: 0.012 in (0.30 mm)
• Nom. Diameter: 0.145 in (3.68 mm)

Standards:

• Voltage Rating: 300 V
• Operating Temperature: -70°C To +200°C

Applications:

• Industrial Control, Raceways, Cable trays and ducts, Digital Control, Instruments (4-20ma, 0-10v, ...), low voltage digital control (24v, …), encoders, control circuits, distributed control
