Belden 83393 20 AWG 2 Conductor 7x28 Stranding Tinned Copper 2000V Electronic Cable

Description:-

High Temperature Electronic, 2 Conductor 20 AWG (7x28) Tinned Copper, FEP Insulation, Overall Beldfoil Shield, Silicone Outer Jacket, AWM 4516

Insulation:-

• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Thickness: 0.020 in (0.51 mm)
• Nom. Insulation Diameter: 0.077 in (2.0 mm)

Outer Shield:-

• Shield Type: Tape
• Material: Textile (Conductive)
• Coverage: 100%

• Shield Type: Tape
• Material: Bi-Laminate (Alum+Nomex)
• Coverage: 100%
• Drainwire Type: 20 AWG (7x28) TC - Tinned Copper

Outer Jacket:-

• Material: Silicone Rubber
• Nom. Thickness: 0.037 in (0.94 mm)
• Nom. Diameter: 0.242 in (6.15 mm)
• Overall Cable Diameter (Nominal): 0.242 in (6.15 mm)

Standards:-

• Operating Temperature Range: -70°C to +150°C
• Voltage Rating: 2000 V DC (Through Jacket), 600 V (UL AWM 4516)

Applications:-

• extreme high/low temperature environments; low voltage analog signals (4-20ma, 0-10v, ...); low voltage control (24v, …); line level audio; voice communications; panel wiring

Specifications:-

• Size (AWG): 20
• No. of Conductor: 2
• Stranding: 7x28
• Conductor Material: TC - Tinned Copper
• Part Number: 83393
