Belden 29535 500 MCM 3 Conductor Bare Copper 2000V Variable Frequency Drives Cable

Description:

Belden Basics VFD, 3 Conductor 500MCM (37x.1162") Bare Copper XLPE Insulation M4 Color Code + 2AWG Symmetrical Segmented Ground (3 of 6 AWG) Bare Copper Stranded in Continuous Contact with Overall Copper Tape Helically Applied Shield, Black PVC Outer Jacket, 2000V TC-ER 90C Dry/Wet 1000V CSA 22.2 No. 230 TC SUN RES DIR BUR Oil Resistant.

Insulation:

Element: Conductor(s):-
Material: XLPE - Cross-Linked Polyethylene (Thermoset)
Nom. Thickness: 0.105 in (2.67 mm)
Nom. Insulation Diameter: 0.999 in (25.4 mm)

Outer Shield:

• Shield Type: Helical Tape
• Material: Bare Copper (BC)
• Coverage: 100%

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.110 in (2.79 mm)
• Nom. Diameter: 2.41 in (61.2 mm)
• Overall Cable Diameter (Nominal): 2.41 in (61.2 mm)

Standards:

• Operating Temperature: -40°C To +90°C
• Voltage Rating: 2000 V (TC, UL44), 1000 V (CSA TC)

Applications:

• Variable Frequency Drives (VFD); AC Motor and Drive Systems
