Belden 19227 18 AWG 2 Conductor 16x30 Stranding Bare Copper 300V Portable Cordage Cable

Description:-

Portable Cordage, 2 Conductor 18 AWG (16x30) Bare Copper, EPDM Insulation, CPE Outer Jacket, UL Type SJO.

Insulation:-

• Material: EPDM - Ethylene Propylene Diene Monomer
• Nom. Thickness: 0.031 in (0.79 mm)
• Nom. Insulation Diameter: 0.110 in (2.79 mm)

Outer Jacket:-

• Material: CPE - Chlorinated Polyethylene (Thermoset)
• Nom. Thickness: 0.035 in (0.89 mm)
• Nom. Diameter: 0.29 in
• Overall Cable Diameter (Nominal): 0.29 in
• Separator: Paper Tape

Standards:-

• UL Voltage Rating: 300 V
• Operating Temperature Range: -20°C To +90°C

Specifications:-

• Size (AWG): 18
• No. of Conductors: 2
• Stranding: 16x30
• Conductor Material: BC - Bare Copper
• Part Number: 19227
