1568241727 - 3mm PVC Conductor Markers on 250 Reel, RoHS Compliant (Pack of 250)

1568241727 - 3mm PVC Conductor Markers on 250 Reel, RoHS Compliant (Pack of 250)

SKU: SKU: 1568241727 Download PDF

Variant:
  • 1568241727 - 3mm PVC Conductor Markers on 250 Reel, RoHS Compliant (Pack of 250)
Regular price Now $14.91
Regular price BEFORE   $0.00 Sale price Now $14.91
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CLI C 02-6 GE/SW A2 CD conductor and cable marker, tailored for precision with dimensions measuring 13 to 3 mm in diameter and a width of 34 mm Crafted from soft PVC without the presence of Cadmium, this product meets stringent RoHS compliance standards Each reel contains 250 markers and operates effectively in temperatures ranging from -30°C to 80°C Notably, it contains no hazardous substances exceeding 0.

1 wt% Featuring hot-embossing printing with mixed characters displayed horizontally, this marker is ideal for diverse industrial applications.

Features and Benefits:

    •Compliant with RoHS without exemption.

    •Reel supply form with 250 markers.

    •Operating temperature range of -30 to 80 °C.

    •Hot-embossed printing with horizontal orientation.

    •Recommended for the process and machinery industries..

Specifications:

 Depth 3.5 mm
 Height 6 mm
 Width 3.4 mm
 Conductor cross-section (max) 1.5 mm²
 Conductor cross-section (min) 0.2 mm²
 Conductor O.D. (max) 3 mm
 Conductor O.D. (min) 1.3 mm
 Cross-section for connected wire 0.2 - 1.5 mm²
 UL 94 flammability rating V-0
 Basic material PVC, soft, without Cadmium
 Halogen Yes
 Imprint A2
 Number of markers per combination 1 Reel = Conductor and cable markers
