UT372D 2-in-1 Tachometer

UT372D 2-in-1 Tachometer

SKU: UT372D   Download PDF

Qty:
Now $12,599.00   Web pricing policy
BEFORE   Now $12,599.00 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information
Resources

Description:

UT372D 2-in-1 Tachometer is a reliable and safe tachometer, which combines contact and non-contact measurement modes It is mainly used to measure Revolutions Per Minute(RPM), frequency, surface velocity and length in the fields of motors, fans, automobiles, papermaking, etc Features include certificates from CE and UKCA, as well as support for multiple languages including EN, FR, DE, IT, ES, SV, PL, CZ.

Additional characteristics involve contact and non-contact measurements, MAX/MIN/AVG/HOLD functions, a rotatable LCD backlight screen, unit conversion capabilities, Bluetooth APP functionality, auto power off feature, data storage for 10 groups, and two measurement buttons.

Features and Benefits:

    •Contact and non-contact measurements.

    •MAX/MIN/AVG/HOLD functionality.

    •Rotatable LCD backlight screen.

    •Unit conversion.

    •Bluetooth APP compatibility.

    •Auto power off feature.

    •Data storage.

    •Two measurement buttons.

Specifications:

 Non-contact rotational velocity (RPM) range 1-99,999
 Non-contact frequency (Hz) range 1-1,666
 Non-contact count (REV) range 1-99,999
 Target distance (mm) 50~500
 Contact rotational velocity (RPM) range 1-19,999
 Contact frequency (Hz) range 1-333
 Surface velocity (m/min) range for 0.1m wheel 0.1-1,999
 Surface velocity (ft/min) range for 0.1m wheel 0.4-6,550
 Surface velocity (in/min) range for 0.1m wheel 4-78,700
 Surface velocity (m/min) range for 6" wheel 0.15-1,524
 Surface velocity (ft/min) range for 6" wheel 0.5-5,000
 Surface velocity (in/min) range for 6" wheel 6-60,000
 Length measurement (m/ft/in) range 0-99999
 Accuracy ±0.02% ±1 digit
 Measurement modes Contact RPM/Non-contact RPM/counting/frequency/Surface velocity/length
 Contact measurement unit m/min, ft/min, in/min,m,ft,in
 Statistical measurement Max/Min/Last reading/Average
 Data storage groups 10
 Operating temperature/humidity 0°C~50°C; ≤80%RH
 Storage temperature -20°C~60°C; ≤80%RH
 Drop test height (m) 1
 Auto power off duration (minutes) 15
 Product color Red and grey
 Product size (mm) 176 × 63 x 38
 Battery type AAA 1.5V ×3
