Temperature data logger for one external Pt1000 probe

Temperature data logger for one external Pt1000 probe

SKU: U0111 Download PDF

Sold out
Web pricing policyShipping calculated at checkout.
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Resources

Description:

Datalogger is designed to record temperature from one external Pt1000 probe The recording is performed in a non-volatile electronic memory The data can be transferred to a PC via USB-C In case of exceeded set limits alarms are indicated by LED, LCD and acoustically by built-in beeper The device includes Traceable calibration certificate with declared metrological traceability of etalons is based on requirements of EN ISO/IEC 17025 standard.

Features and Benefits:

    •Traceable calibration certificate with declared metrological traceability.

    •Recording performed in a non-volatile electronic memory.

    •Data transfer to PC via USB-C.

    •LED, LCD, and acoustic alarms for exceeded limits.

Specifications:

 Temperature Sensor external probe Pt1000
 Measuring Range -90 to +260 °C
 Accuracy ±0.2°C; ±0.2 % of the measurement value in a range of +100 to +260 °C
 Resolution 0.1 °C
 Response Time according to the connected probe
 Operating Temperature -30 to +70 °C
 Channels 1x external temperature probe
 Memory 500,000 values in noncyclic logging mode; 350,000 values in cyclic record mode
 Recording Interval adjustable from 1 s to 24 h
 Display and Alarm Refresh adjustable 1 s, 10 s, 1 min
 Recording Mode noncyclic - data logging stops after filling the memory; cyclic - after filling memory oldest data is overwritten by new
 Real Time Clock year, leap year, month, day, hour, minute, second
 Power Lithium battery 3.6 V, size AA
 Protection Class IP67
 Dimensions 61 x 93 x 32 mm
