SKU: SKU: IDC-360B-24 Download PDF
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances ** Images are for display purposes only refer to Product Technical Details for accurate information on the product. In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Fully Isolated ConverterIDC-360 series is a complete line of high efficiency 360 Watt isolated DC-DC converters suitable for applications requiring galvanic isolation between the input and the output IDC-360B-24 isolated DC-DC converter provides a highly regulated output DC voltage of 245 Volts for an input DC voltage range of 20-35 Volts and rated output current of 15 Amps Features of this isolated DC-DC converter include compact housing, fold-back current limiting and protection against short circuit, overheating, overvoltage and reverse polarity connection. The unit comes with ¼” push-on flat blade “quick disconnect” connectors IDC-360B-24 isolated DC-DC converter is EMI/EMC compliant and conforms to European standards EN50081-1 (for EMI), EN50082-1 (for EMC) and the European Automotive Directive 95/54/EC IDC-360 series is a complete line of high efficiency 360 Watt isolated DC-DC converters suitable for applications requiring galvanic isolation between the input and the output. IDC-360B-24 isolated DC-DC converter provides a highly regulated output DC voltage of 245 Volts for an input DC voltage range of 20-35 Volts and rated output current of 15 Amps Features of this isolated DC-DC converter include compact housing, fold-back current limiting and protection against short circuit, overheating, overvoltage and reverse polarity connection The unit comes with ¼” push-on flat blade “quick disconnect” connectors. IDC-360B-24 isolated DC-DC converter is EMI/EMC compliant and conforms to European standards EN50081-1 (for EMI), EN50082-1 (for EMC) and the European Automotive Directive 95/54/EC.
Features and Benefits:
•High efficiency 360 Watt isolated DC-DC converter.
•Provides a highly regulated output DC voltage of 24.5 Volts.
•Input DC voltage range of 20-35 Volts.
•Rated output current of 15 Amps.
•Compact housing.
•Fold-back current limiting.
•Protection against short circuit, overheating, overvoltage, and reverse polarity connection.
•Comes with ¼” push-on flat blade quick disconnect connectors.
•EMI/EMC compliant.
•Conforms to European standards EN50081-1 and EN50082-1.
•Compliant with the European Automotive Directive 95/54/EC.
Specifications:
