CPC1211 12.1 Rugged All-Weather Sunlight Readable All-In-One Panel Car PC
CPC1211 12.1 Rugged All-Weather Sunlight Readable All-In-One Panel Car PC
SKU: SKU: CPC1211
Couldn't load pickup availability
Description:
The Xenarc CPC1211 121 Rugged All-In-One Panel Car PC is the most versatile and all-encompassing product in Xenarc Technologies’ lineup This 16:9 1000 NIT High Bright Panel Car PC is IP65 and IK08 rated and includes an optically bonded capacitive touchscreen, making it ideal for any harsh industrial environment It utilizes Intel's automotive and industrial grade, extended temperature E3845 Quad-Core 1.
91Ghz CPU with a wide operating temperature range Its automatic ACC shutdown control allows the computer to automatically shut down when the ignition is turned off, perfect for automotive and boat applications The 121 inch touch panel is optically bonded to the LCD panel, enhancing clarity, contrast, and durability This rugged panel PC outperforms other automotive grade panel Car PCs with a wider operating temperature range of -30C ~ 85C (-22F ~ 185F) and uses an IPS panel, offering a wider viewing angle and accurate colors.
A high contrast ratio of 1000:1 provides crisper images and vivid colors, even in direct sunlight Designed for those looking for a rugged, bright, all-in-one panel Car PC, usable in diverse environments, the CPC1211's versatility extends beyond its usability Unlike most panel PCs which provide water protection only at the front, the PPC1211 is IP65 on all sides with included waterproof cables The casing is designed to function as a stand-alone panel Car PC or a panel mounted Car PC, with VESA standard mounting holes on the back for various mounting options.
The IK08 rating further enhances its resistance to vandalism and shock.
Features and Benefits:
•IP65 / NEMA4 Rated Water and Dust Resistance.
•Intel Atom E3845 Quad-Core 1.91Ghz Automotive Grade CPU.
•12.1 Inch 1280 x 800 IPS Wide Viewing Angle Display.
•1,000NIT Sunlight Readable with Long Life LED Backlight.
•Toughened Projected Capacitive Multi-Touch Touchscreen.
•Optical Bonding, Anti-Reflective and Anti-Fingerprint Coating.
•2G/3G/4G LTE Cellular Internet.
•802.11 B/G/N/AC WiFi, Bluetooth 4.0.
•Dual Gigabit Ethernet.
•USB 3.0, RS232 Serial Ports.
•Built-in GPS and G-Sensor.
•Rugged Aluminum and Stainless-Steel enclosure.
•Supports 9V DC ~ 36V DC.
•Transportation - Marine, Air, Heavy Vehicles, Mining, Weigh Stations, Fleet Management, Telematics, In-Car Computing, Public Transit, Cargo.
•System Integration - Machinery Controls, Factory Automation, Environmental Monitoring, Home Automation, Military, Smart Home.
•Point of Sale - Hospitality, Digital Signage, Self-Service Kiosks, Outdoor Kiosks and Signage, Casino.
•Data Monitoring - Cloud, IoT, Medical, Logistics, Inventory Management, Oil & Gas/Utilities, Law Enforcement, Broadcasting, Veterinary, First Person View.
•Broadcast & Production - Broadcast Stations, Mobile Production Vehicles, Field Rugged Deployment for your mobile workforce, Studio Video Production.
Specifications:
| Processor | Intel Atom E3845 Automotive Grade Processor (4 Cores, 2M Cache, 1.91Ghz) |
| Memory | 8GB RAM DDR3L-1333 |
| Internal Storage | 256GB M.2 2280 Solid State Drive |
| External Storage | Micro SD Card Slot x 1 |
| Operating System | Windows 10 IOT 2019 LTSC |
| Display | 12.1-Inch Automotive Grade 1280 x 800 IPS LCD |
| Display Brightness | 1000 cd/m² Sunlight Readable |
| Display Contrast Ratio | 1000:1 |
| Display Viewing Angle | 178° Horizontal, 178° Vertical |
| Display Response Time (Tr+Tf) | 25ms (Typ.) |
| Touchscreen | Projected Capacitive Multi-Touch |
| Sim Card | 1.8/3.3V SIM Card |
| Cellular Network Support | 2G/3G/4G - GSM(B2/5), UMTS(B2/4/5), LTE-FDD(B2/4/5/12/13/17/28) |
| Bluetooth | Bluetooth 4.0 |
| WiFi | 802.11 A/B/G/N/AC (2.4G and 5G) |
| Ethernet | RJ45 10/100/1000Mbps Port x 2 |
| Navigation | GPS |
| USB | USB 3.0 x 4 |
| Serial Port | RS232 Serial port x 2 |
| GPIO | 8 Bit Programmable GPIO x 1 |
| Audio | Built-in Waterproof Speaker x 2, Audio Input x 1, Audio Output x 1 |
| Video Output | HDMI Output x 1 |
| G-Sensor | Built-in G-Sensor |
| Power Switch | Built-in Power Switch x 1, Remote Power Switch x 1, ACC Shutdown Control x 1 |
| Operating Voltage Range | DC 9V ~ 36V |
| Power Consumption | ≤ 40W |
| Operating Temperature | -22°F ~ 185°F (-30°C ~ 85°C) |
| Storage Temperature | -22°F ~ 185°F (-30°C ~ 85°C) |
| Relative Humidity | 5% ~ 95% |
| Vibration | Operating Random Vibration Test (5-500Hz, 1.0Grms), IEC 60068-2-64 standard |
| Shock | Operating Shock Test, 10G peak acceleration (11ms duration), IEC 60068-2-27 standard |
| MTBF (Mean Time Between Failures) | > 55,000 Hours or > 6.2 Years of continuous operation |
| Dimension (mm) | 312W x 230H x 67.2D |
