Belden 89901 20 AWG 4 Pair 7x28 Stranding Tinned Copper 300V Transceiver 10BASE5 Cable

Description:-

IEEE 802.3 Ethernet Transceiver 10BASE5, 20 AWG stranded (7x28) tinned copper conductors, plenum, FEP insulation, twisted pairs, individually foil shielded pairs, overall polyester isolation tape + Duofoil + tinned copper braid shield (95% coverage), drain wire, light gray fluorocopolymer (PVDF) jacket, plenum rated.

Insulation:-

Element: Data Pair(s)
• Material: FEP - Fluorinated Ethylene Propylene (Foam)
• Nom. Insulation Diameter: 0.076 in (1.9 mm)

Element: PowerPair(s)
 • Material: FEP - Fluorinated Ethylene Propylene
• Nom. Insulation Diameter: 0.060 in (1.5 mm)

Inner Shield:-

Element: Data Pair(s)
• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Foil Out

Element: Power Pair(s)
• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Foil Out

Outer Shield:-

• Layer: 1
• Shield Type: Tape
• Material: Tri-Laminate (Alum+Poly+Alum)
• Coverage: 100%
• Drainwire Type: 22 AWG (7x30) TC - Tinned Copper
• Polyester Isolating tape under DuoFoil

• Layer: 2
• Shield Type: Braid
• Material: Tinned Copper (TC)
• Coverage: 93%

Outer Jacket:-

• Material: PVDF - Polyvinylidene Fluoride
• Nom. Diameter: 0.370 in (9.40 mm)
• Overall Cable Diameter (Nominal): 0.370 in (9.40 mm)

Applications:

10Base5 Transceiver

Standards:-

• UL Voltage Rating: 300 V (CMG)
• Nom. Characteristic Impedance: 78 Ohms
• Operating Temperature Range: -20°C to +150°C

Specifications:-

Element: Data Pair(s)
• Size (AWG): 20
• No. of Pair: 3
• Stranding: 7x28
• Conductor Material: TC - Tinned Copper

Element: Power Pair(s)
• Size (AWG): 20
• No. of Pair: 1
• Stranding: 7x28
• Conductor Material: TC - Tinned Copper
• Part Number: 89901
