Belden 8441 22 AWG 1 Pair 7x30 Stranding 300V Audio Control and Instrumentation Cable

Belden 8441 22 AWG 1 Pair 7x30 Stranding 300V Audio Control and Instrumentation Cable

SKU: NES8441   Download PDF

Select a gauge:
  • Belden 8441 22 AWG 1 Pair 7x30 Stranding 300V Audio Control and Instrumentation Cable
Length: FT
Enter footage in the box - Cut to one length. Min 1 ft - Max 10000 ft.
Now $1.89 /FT   Web pricing policy
BEFORE   Now $1.89 /FT Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Belden 8441 22 AWG 1 Pair 7x30 Stranding 300V Audio Control and Instrumentation Cable

Description:

Audio, Control and Instrumentation Cable, 1 Pair 22 AWG (7 x 30) Tinned Copper, PVC insulation, 85% Tinned Copper Braid Shield, PVC Jacket, CMG.

Insulation:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.016 in (0.41 mm)

Outer Shield:

• Shield Type: Braid
• Material: Tinned Copper (TC)
• Coverage: 85%
• Drainwire Type: 22 AWG (19x34) TC

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.025 in (0.64 mm)
• Nom. Diameter: 0.194 in (4.93 mm)
• Overall Cable Diameter (Nominal): 0.194 in (4.93 mm)

Standards:

• Voltage Rating: 300 V
• Temperature Rating: -20°C to +80°C
• Nominal Impedance: 45 Ohm

Applications:

• Audio/Speaker, Control and Instrumentation

Specifications:

• Size (AWG): 22
• No. of Pair: 1
• Stranding: 7x30
• Conductor Material: TC - Tinned Copper
• Part Number: 8441
