Belden 8410 25 AWG 1 Conductor 7x33 Stranding EPDM Rubber Jacket 3000V Microphone Cable

Description:-

25 AWG stranded (7x33) composite copper conductor, EPDM rubber insulation, rayon braid + TC braid shield (80% coverage), cotton serve, cotton serve, EPDM rubber jacket.

Insulation:-

• Material: EPDM - Ethylene Propylene Diene Monomer
• Nominal Diameter: 0.154 in
• Nominal Wall Thickness: 0.058 in

Outer Shield:-

• Shield Type: Braid
• Material: Rayon
• Coverage [%]: 80%

• Shield Type: Braid
• Material: Tinned Copper (TC)
• Coverage [%]: 80%

Outer Jacket:-

• Material: EPDM - Ethylene Propylene Diene Monomer
• Nominal Diameter: 0.245 in
• Nominal Wall Thickness: 0.024 in
• Cotton Serve

Standards:-

• Non-UL Voltage Rating: 3000 V DC
• Nom. Characteristic Impedance: 52 Ohm
• Operating Temperature Range: -30°C To +60°C

Applications:-

• Microphone, Musical Instrument

Specifications:-

• Size (AWG): 25
• No. of Conductor: 1
• Stranding: 7x33
• Nominal Diameter: 0.021 in
• Conductor Material: TC+TCCS - Tinned Copper (High Conductivity) + Tinned Copper Covered Steel (High Conductivity)
• Part Number: 8410
