Belden 6500FC 22 AWG 2 Conductor 7x30 Stranding Bare Copper 300V Security and Sound Cable
Belden 6500FC 22 AWG 2 Conductor 7x30 Stranding Bare Copper 300V Security and Sound Cable
SKU: SKU: NES6500FC Download PDF
gauge:
- Belden 6500FC 22 AWG 2 Conductor 7x30 Stranding Bare Copper 300V Security and Sound Cable
- Belden 6500FC 22 AWG 2 Conductor 7x30 Stranding Bare Copper 300V Security and Sound Cable
Enter footage in the box - Cut to one length. Min 1 ft - Max 10000 ft.
Regular price
Now $1.48 /FT
Regular price
BEFORE
Sale price
Now $1.48 /FT
Unit price
per
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
Couldn't load pickup availability
Product Information
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Belden 6500FC 22 AWG 2 Conductor 7x30 Stranding Bare Copper 300V Security and Sound Cable
Description:-
Security, Pro Audio and Intercom Cable, 2 Conductor 22 AWG stranded (7x30) bare copper conductors with FEP insulation, Beldfoil shield, Plenum, Flamarrest jacket with ripcord.
Insulation:-
• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Thickness: 0.006 in (0.15 mm)
• Nom. Insulation Diameter: 0.041 in (1.0 mm)
Outer Shield:-
• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage: 100%
• Drainwire Type: 24 AWG (7x32) TC - Tinned Copper
Outer Jacket:-
• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.015 in (0.38 mm)
• Nom. Diameter: 0.116 in
• Overall Cable Diameter (Nominal): 0.116 in
Standards:-
• UL Voltage Rating: 300 V
• Operating Temperature Range: -20°C To +75°C
Applications:-
• Pro Audio, Intercom/PA Systems, Security Systems
Specifications:-
• Size (AWG): 22
• No. of Conductors: 2
• Stranding: 7x30
• Conductor Material: BC - Bare Copper
• Part Number: 6500FC
Description:-
Security, Pro Audio and Intercom Cable, 2 Conductor 22 AWG stranded (7x30) bare copper conductors with FEP insulation, Beldfoil shield, Plenum, Flamarrest jacket with ripcord.
Insulation:-
• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Thickness: 0.006 in (0.15 mm)
• Nom. Insulation Diameter: 0.041 in (1.0 mm)
Outer Shield:-
• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage: 100%
• Drainwire Type: 24 AWG (7x32) TC - Tinned Copper
Outer Jacket:-
• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.015 in (0.38 mm)
• Nom. Diameter: 0.116 in
• Overall Cable Diameter (Nominal): 0.116 in
Standards:-
• UL Voltage Rating: 300 V
• Operating Temperature Range: -20°C To +75°C
Applications:-
• Pro Audio, Intercom/PA Systems, Security Systems
Specifications:-
• Size (AWG): 22
• No. of Conductors: 2
• Stranding: 7x30
• Conductor Material: BC - Bare Copper
• Part Number: 6500FC
