Belden 3124A 22 AWG 1 Pair 18 AWG 1 Pair Tinned Copper 600V DeviceBus for Square D/Seriplex Cable

Description:-

DeviceBus for Square D/Seriplex, 2 Pair 18+22 AWG (16x30+7x30) Tinned Copper, FPE Insulation, Overall Beldfoil Shield, PVC Outer Jacket, CM.

Insulation:-

Element: 22 AWG
• Material: PE - Polyethylene (Foam)
• Nom. Thickness: 0.0315 in (0.800 mm)

Element: 18 AWG
• Material: PE - Polyethylene (Foam)
• Nom. Thickness: 0.026 in (0.66 mm)

Outer Shield:-

• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage: 100%
• Drainwire Type: 22 AWG (7x30) TC  - Tinned Copper

Outer Jacket:-

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.039 in (0.99 mm)
• Nom. Diameter: 0.308 in (7.82 mm)
• Overall Cable Diameter (Nominal): 0.308 in (7.82 mm)

Standards:-

• Nom. Characteristic Impedance: 120 Ohm
• Operating Temperature Range: -20°C to +75°C
• UL Voltage Rating: 300 V (CM), 600 V (UL AWM 20201)

Applications:-

• Harsh environment, IIoT, factory or process automation, video, audio, data communication, etc.

Specifications:-

Element: 22 AWG
• Size (AWG): 22
• No. of Pairs: 1
• Stranding: 7x30
• Conductor Material: TC - Tinned Copper

Element: 18 AWG
• Size (AWG): 18
• No. of Pairs: 1
• Stranding: 16x30
• Conductor Material: TC - Tinned Copper
• Part Number: 3124A
