Belden 1023A 16 AWG 1 Pair Solid Copper and Constantan 300V Type TX Thermocouple Cable

Description:

Type TX Thermocouple, 1 Pair 16 AWG (Solid) OFHC+Constantan, PVC Insulation Blu, Red Color Code, Overall Beldfoil Shield, Blue PVC Outer Jacket, PLTC ITC CMG AWM 2464 SUN RES.

Insulation:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.021 in (0.53 mm)
• Nom. Insulation Diameter: 0.093 in (2.4 mm)

Outer Shield:

• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage: 100%
• Drainwire Type: 18 AWG (7x26) TC - Tinned Copper

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.037 in (0.94 mm)
• Nom. Diameter: 0.264 in (6.71 mm)
• Overall Cable Diameter (Nominal): 0.264 in (6.71 mm)

Standards:

• Operating Temperature: -30°C to +105°C
• Voltage Rating: 300 V (PLTC, CMG, UL AWM 2464), 150 V (ITC)

Applications:

• Industrial Control, Raceways, Cable trays and ducts, Digital Control, Instruments (4-20ma, 0-10v, ...), low voltage digital control (24v, …), Thermocouple, distributed control system (DCS), programmable logic controller (PLC)
