ARK1086CHSSLT 10 x 8 x 6 Inch PC Enclosure with Knock-Out Base, Hinged Opaque Cover with Stainless Steel Latches

ARK1086CHSSLT 10 x 8 x 6 Inch PC Enclosure with Knock-Out Base, Hinged Opaque Cover with Stainless Steel Latches

SKU: ARK1086CHSSLT Download PDF

Now $19,475.00
BEFORE   Now $19,475.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Resources

Description:

10 x 8 x 6 Inch PC Enclosure with Knock-Out Base, Hinged Opaque Cover with Stainless Steel Latches This is designed to meet various UL and cUL Type ratings, ensuring robust protection in diverse environments The enclosure features a hinged opaque cover and comes with stainless steel latches for enhanced security It is suitable for a range of applications where robust protection and reliability are paramount.

Features and Benefits:

    •Hinged cover for easy access.

    •Base with 10-32 brass inserts for secure mounting.

    •LATCHED cover with formed in place PUR gasket.

    •Stainless hinge pin for durability.

    •Knock-outs for 1/2 and 3/4 inch conduits.

    •Quick release latches for convenience.

    •Accessory screws included for panel mounting.

Specifications:

 Dimensions (inches) 10 x 8 x 6
 Material Polycarbonate
 Base color RAL 7035 - light grey
 Cover color Transparent
 Gasket material Polyurethane
 Temperature (°F) -40 … 175
 Temperature (°C) -40 … 80
 UL/cUL Type UL/cUL 4, 4X, 6, 6P, 12, 12K and 13
 Ingress Protection IP66; IP67
 Impact Resistance IK09
 Electrical insulation Fully insulated
 Halogen free Yes
 UV resistance UL 508
 Flammability Rating UL94-5VA (f1)/Cover: UL94-V0 (f1)
 Glow Wire Test 960 °C
