8561089 - PC Enclosure, Hinged opaque screw cover w/S.S. Quick release latch

8561089 - PC Enclosure, Hinged opaque screw cover w/S.S. Quick release latch

SKU: AR884CHSS Download PDF

Now $15,353.00
BEFORE   Now $15,353.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Resources

Description:

8 x 8 x 4 Inch PC Enclosure, Hinged opaque screw cover w/SS Quick release latch This robust enclosure is designed to meet various UL Type ratings including NEMA 4, 4X, 6, 6P, 12, 12K and 13 with an ingress protection of IP66 and IP67 The enclosure features a hinged cover, a base with 10-32 brass inserts, and quick release latches for easy access It is suitable for mounting and includes accessory screws for panel mounting.

Features and Benefits:

    •UL/cUL Type rated for NEMA 4, 4X, 6, 6P, 12, 12K and 13.

    •Ingress Protection ratings of IP66 and IP67.

    •Hinged cover with stainless steel quick release latch for easy access.

    •Constructed from durable polycarbonate material.

    •Halogen free and UV resistant.

    •Impact resistance rated IK09.

    •Fully insulated with excellent flammability rating UL94-5VA (f1).

Specifications:

 Dimensions (inch): 8 x 8 x 4
 Dimensions (mm): 203.2 x 203.2 x 101.6
 Material: Polycarbonate
 Base color: RAL 7035 -light grey
 Cover color: RAL 7035 -light grey
 Gasket material: Polyurethane
 Temperature (°F): -40 … 175
 Temperature (°C): -40 … 80
 Impact Resistance (EN 62262): IK09
 Ingress Protection (EN 60529): IP66; IP67;
 Electrical insulation: Fully insulated
 Halogen free: Yes
 UV resistance: UL 508
 Glow Wire Test (IEC 60695): 960 °C
