8537380000 - 25-Pole Female D-Sub Connector with Tension-Clamp Connection

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the RS SD25 BZ, a robust 25-pole female D-sub connector that adheres to IEC 60807 and DIN 41652 standards Engineered with a tension-clamp connection, this connector is a reliable choice for various applications It is RoHS compliant and fulfills specific exemption criteria With a maximum voltage rating of 100 V and a current capacity of 1 A, it’s suitable for both storage and operational settings.

The connector operates efficiently within a temperature range of 0 °C to 55 °C, and can be stored in environments as cold as -40 °C and as warm as 70 °C.

Features and Benefits:

•RoHS compliant with exemption status.

•Tension-clamp connection design.

•Compatible with IEC 60807 / DIN 41652 standard.

•25-pole female configuration.

•Insulation coordinated according to DIN EN 50178.

Specifications:
