8120032N Cabinet Style, PC
8120032N Cabinet Style, PC
SKU: SKU: ARCA 505021 NO-MP
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Cabinet Style, PC with grey cover and swing handle, including hinges on the long side The cabinet enclosure features a PUR gasket and comes with 3mm double bit locks with keys, screws for mounting, and a door guide.
Features and Benefits:
•UL Type NEMA 1, 4, 4X, 12 and 13 rated.
•Ingress Protection IP66.
•Impact Resistance IK10.
•Completely insulated and halogen-free.
•UV resistance compliant with UL 508.
•Temperature range from -40 to 175 °F (-40 to 80 °C).
Specifications:
| Dimensions (inches) | 19.69 x 19.69 x 8.58 |
| Dimensions (mm) | 500 x 500 x 210 |
| Material | Polycarbonate, PC |
| Base color | RAL 7035 - light grey |
| Cover color | RAL 7035 - light grey |
| Gasket material | Polyurethane (PUR) |
| Temperature °F (continuous) | -40 … 175 |
| Temperature °C (continuous) | -40 … 80 |
| UL/cUL Type | UL/cUL 1, 4, 4X, 12 and 13 |
| Ingress Protection | IP66 |
| Impact Resistance | IK10 |
| Electrical insulation | Totally Insulated |
| Halogen free | Yes |
| UV resistance | UL 508 |
| Flammability Rating | UL94-5VA (f1) |
| Glow Wire Test | 960 °C |
