60140 - Chrome-Vanadium Double Ended Spanner E14xE18, 180mm Long
60140 - Chrome-Vanadium Double Ended Spanner E14xE18, 180mm Long
SKU: SKU: 60140
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Experience precision with the double-ended ring spanner, featuring external TX sizes of E14 and E18 Crafted from durable chrome-vanadium steel (31CrV3), this tool is finished with a chrome plating for added resilience With a total length of 180 mm, it is specifically engineered for accurate applications, making it an essential addition to your toolkit.
Features and Benefits:
•Made of chrome-vanadium steel 31CrV3.
•Chrome-plated for durability.
•Total length of 180 mm for versatile use.
Specifications:
| Total length [mm] | 180 mm |
| Weight | 0.160 lbs |
| Tip size TX 1 (protrude) [mm] | 12.90 mm |
| Tip size TX 2 (protrude) [mm] | 16.70 mm |
| Width of head 1 [mm] | 17.0 mm |
| Width of head 2 [mm] | 21 mm |
| Head height 1 [mm] | 8.5 mm |
| Head height 2 [mm] | 9.5 mm |
| Material | 31CrV3 |
| Surface | chrome-plated |
| Screw diameter DIN 7984 | M12 - M14 |
| Screw diameter ISO 4762 | M12 - M14 |
