Description:
This robust tool is equipped with a pressed-in phosphated pin and features a hand-operated knurled grip along with a polished drive end for easy handling It adheres to DIN 7422 standards and incorporates a square drive that meets DIN 3120 - C 63 and ISO 1174 specifications, complete with a ball retention groove for added functionality Crafted from high-quality chromium vanadium steel, this tool promises exceptional durability and performance.
Features and Benefits:
•Pressed-in phosphated pin for durability.
•Hand-operated knurled grip for easy handling.
•Brightly polished drive end for enhanced visibility.
•Complies with DIN standards for reliable quality.
•Constructed from chromium vanadium steel for strength.
Specifications:
| Total width [mm] | 12 mm |
| Total length [mm] | 37 mm |
| Drive mount, square [metric] | 6.3 mm |
| Drive connector square [inch] | 1/4" |
| Standard | DIN 7422 DIN 3120 – C 6,3 ISO 1174 |
| Insert Ø Actuator | 12 mm |
| Material | Chrome-vanadium steel |
| Compliance | compliant |
| Width across flats 1 [mm] | 4 |
| Safety | Ball Catching Cricket |
| Tip length | 15.0 mm |
