40102-502 30.5mm Mushroom and Rope Pull Operators
40102-502 30.5mm Mushroom and Rope Pull Operators
SKU: SKU: 40102502 Download PDF
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
The 305mm Mushroom and Rope Pull Operators is a hand-operated control circuit device, designed for heavy-duty use with electromagnetic equipment Its body is constructed from die-cast zinc, ensuring durability The ergonomic red mushroom-shaped plunger is molded from DuPont Delrin 100ST Acetal, providing superior impact resistance This operator is built to accept up to three tiers of two contact blocks, enhancing its versatility.
Features and Benefits:
•Ergonomic red mushroom plunger for ease of use.
•Made from durable die-cast zinc.
•Impact-resistant material for the plunger.
•Supports up to three tiers of contact blocks.
Specifications:
| Operator Color | Red |
| Operator Material | Die-cast zinc |
| Size | 2.00 in. Plastic Mushroom |
| Padlock Feature | Yes |
| Switch Type | Maintained |
| Operating Force | 8.0 lb |
| Plunger Head Operator Replacement | 43200-042 |
| Old Catalog Number | R102 |
| Operating Type | Maintained |
| Nema Rating | Nema 12/13, IP 65 |
| UL/NISD | E357870 |
