40102-222 30.5mm Mushroom and Rope Pull Operators
40102-222 30.5mm Mushroom and Rope Pull Operators
SKU: SKU: 40102222 Download PDF
Couldn't load pickup availability
Description:
The 305mm Mushroom and Rope Pull Operators are hand-operated control circuit devices rated as 'Heavy Duty', typically used with electromagnetic equipment The body is constructed from die-cast zinc, while the red mushroom ergonomic shaped plunger is made from DuPont Delrin 100ST Acetal, providing improved impact resistance and featuring a solid color throughout This operator will accommodate up to three tiers of two contact blocks.
Features and Benefits:
•Ergonomic red mushroom shaped plunger for better handling.
•Heavy Duty rating suitable for electromagnetic equipment.
•Constructed from durable die-cast zinc.
•Impact-resistant plunger made from DuPont Delrin 100ST Acetal.
•Can accept multiple tiers of contact blocks.
Specifications:
| Operating Force: | 8.0 lb |
| Contact Block(s) Included: | None |
| Operator Material: | Die-cast zinc |
| Plunger Head Operator Replacement: | 43200-042 |
| Old Catalog Number: | R102 |
| Switch Type: | Maintained |
| Nema Rating: | Nema 12/13, IP 65 |
