40102-214 30.5mm Mushroom and Rope Pull Operators
40102-214 30.5mm Mushroom and Rope Pull Operators
SKU: SKU: 40102214 Download PDF
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
The 305mm Mushroom and Rope Pull Operators is a hand-operated control circuit device rated 'Heavy Duty', primarily used with electromagnetic equipment The body is constructed from die-cast zinc, enhancing durability It features a yellow mushroom ergonomic plunger made from DuPont Delrin 100ST Acetal, providing better impact resistance and uniform color throughout.
Features and Benefits:
•Nema 12/13, IP 65 rating for protection against dust and water.
•Ergonomic design for ease of use.
•Positive opening contact ensures safety.
•Includes two contact blocks: (2) NC / (1) NO.
•Maintained switch type for reliable operation.
•Padlock feature enhances security.
Specifications:
| Operator Color | Yellow |
| Operator Material | 2.00 in. Plastic Mushroom |
| Padlock Feature | Yes |
| Switch Type | Maintained |
| Contact Block(s) Included | (2) 52702 + 50724 (2) NC / (1) NO |
| NC Opens upon Removal | |
| Operating Force | 12.0 lb |
| Operating Type | Maintained |
